Q ACOUSTICS CONCEPT 30

Q ACOUSTICS CONCEPT 30 Specification

Aux Option
No

Bluetooth
Yes

Auto Memory
No

Player Type
Passive Bookshelf Speakers

Material
High-quality MDF cabinet with Gelcore construction

Channels
2

Control Device
Manual

FM Turner
No

USB Port
No

Display
No

Progressive Scan
No

Power
75W (recommended amp power)

Weight (kg)
12.6 kg (Pair)

Color
Black / Silver / White

Sensitivity
87 dB

Mounting Type
Bookshelf / Stand-mount

Frequency Response
54 Hz 30 kHz

Recommended Room Size
Small to Medium

Impedance
6 Ohms

Finish
Gloss Black, Gloss Silver, Gloss White

Crossover Frequency
2.4 kHz

Enclosure Technology
Gelcore Cabinet Construction with P2P Bracing

Speaker Terminals
Bi-wireable

Drivers
1 x 125 mm Mid/Bass Driver, 1 x 25 mm High-Frequency Driver

Dimensions (HxWxD)
320 x 180 x 343 mm per speaker

Speaker Type
2-way Reflex Ported

Grille
Magnetic Removable Grille

About Q ACOUSTICS CONCEPT 30

Hifi Bookshelf Speakers: Q Concept 30 passive speakers let you feel like you're listening to your favorite music live. The 0.9" high-frequency driver is hermetically sealed and mechanically isolated from the front baffle, protecting it from internal resonances from the 5" mid/bass driver for a truly refined sound.
Quiet Cabinet Design: The stereo speakers' Gelcore cabinet construction reduces higher frequency noise, while P2P internal bracing stiffens the cabinet to minimize lower frequency vibrations. These innovations improve the focus of stereo image and provide an extended holographic soundstage.

Advanced Cabinet Engineering

The Gelcore cabinet construction in the Q ACOUSTICS CONCEPT 30 uses a multi-layered MDF design with a unique damping material sandwiched between layers. This innovation, together with P2P bracing, isolates unwanted vibrations, resulting in a cleaner, distortion-free audio experience. Whether music or movies, the cabinet ensures pure sound delivery.

Versatile Aesthetic Options

Choose from Gloss Black, Gloss Silver, or Gloss White finishes to complement modern interiors. The Concept 30 offers magnetic removable grilles for easy customization-perfect for users who appreciate both style and sonic clarity. Its compact bookshelf or stand-mount design adapts well to small and medium room sizes.

Precision-Tuned Drivers and Performance

Equipped with a 125 mm mid/bass driver and a 25 mm tweeter, the Concept 30 delivers dynamic and detailed sound. The crossover frequency of 2.4 kHz results in seamless integration between drivers, while the wide frequency response ensures lifelike music reproduction. Enjoy immersive listening with impressive sensitivity and impedance, optimized for quality amplification.

FAQ's of Q ACOUSTICS CONCEPT 30:

Q: How do I install and set up the Q ACOUSTICS CONCEPT 30 speakers for optimal sound?

A: Place each Concept 30 speaker on a sturdy bookshelf or compatible stand, approximately ear level when seated. Utilize the bi-wireable terminals for secure connections to your amplifier (recommended power: 75W per channel), ensuring correct polarity. Removing the magnetic grille is optional and based on personal preference.

Q: What benefits does Gelcore cabinet construction provide for the Concept 30?

A: The Gelcore cabinet technology significantly minimizes resonance and vibration within the enclosure. This proprietary layering system enhances audio clarity by reducing distortion, allowing the drivers to deliver accurate and expressive sound even at higher volumes.

Q: Where is the best location to use Concept 30 speakers in a home environment?

A: The Concept 30 is optimized for small to medium-sized rooms. Position them away from corners and reflective surfaces when possible. For enhanced performance, consider stand mounting in dedicated listening areas, living rooms, or home offices.

Q: What process should I follow to bi-wire the Concept 30 speakers?

A: To bi-wire, use speaker cables that have separate conductors for the low- and high-frequency drivers. Connect each pair of terminals on the Concept 30 to the corresponding outputs on your amplifier, ensuring tight, clean connections and correct polarity for optimal signal delivery.

Q: Can I connect Concept 30 speakers directly to mobile devices or use wireless features?

A: No, the Concept 30 speakers are passive and require connection to a dedicated stereo amplifier. They do not support Bluetooth, USB ports, or aux inputs. Audio sources must be routed through an amplifier with speaker outputs.

Q: What materials are used in the construction of the Concept 30 speakers?

A: The Concept 30 features high-quality MDF cabinets with Gelcore technology and precision engineered drivers. The use of advanced bracing and finishing materials contributes to both its acoustic performance and sophisticated appearance.
